OVERVIEW



Category: Brass Wire Mesh / Copper Wire Mesh/ Phosphor Bronze Wire Mesh

Material: Brass wire, phosphor bronze wire, or copper wire

l  Yellow brass (copper 65%, zinc 35%)

l  Purple copper wire (copper content 99.8%)

l  Phosphorus copper wire (copper 85% -90%, 5% SN -15%)







Advantages: has good electrical conductivity, heat transfer performance, non-magnetic, corrosion-resistant, low ductility, abrasion resistance.
Application: Separation and sifting kinds pellet, grain, porcelain earth and glass, chinaware printing, filter liquid, etc. Widely used in industrial filtration, petroleum, chemical, printing and other industries
Specifications: brass wire cloth 6-160mesh; copper wire cloth 10-60mesh; phosphor bronze wire cloth 120-360mesh
Width: 0.914M, 1M, 1.5M, And Length/roll: 30M
Weaving methods: Plain weaves, Twill weave or Dutch weave


Mesh	Wire Diameter			Mesh Size(MM)
	SWG	mm	inch
6	22	0.711	0.028	3.522
8	23	0.61	0.024	2.565
10	25	0.508	0.02	2.032
12	26	0.457	0.018	1.66
14	27	0.417	0.016	1.397
16	29	0.345	0.014	1.243
18	30	0.315	0.012	1.096
20	30	0.315	0.0124	0.955
22	30	0.315	0.0124	0.84
24	30	0.315	0.0124	0.743
26	31	0.295	0.0116	0.682
28	31	0.295	0.0116	0.612
30	32	0.247	0.011	0.573
32	33	0.254	0.01	0.54
34	34	0.234	0.0092	0.513
36	34	0.234	0.0092	0.472
38	35	0.213	0.0084	0.455
40	36	0.193	0.0076	0.442
42	36	0.193	0.0076	0.412
44	37	0.173	0.0068	0.404
46	37	0.173	0.0068	0.379
48	37	0.173	0.0068	0.356
50	37	0.173	0.0068	0.335
60×50	36	0.0076	0.0076
60×50	37	0.0068	0.0068
60	37	0.0068	0.0068	0.25
70	39	0.132	0.0052	0.231
80	40	0.122	0.0048	0.196
90	41	0.112	0.0044	0.17
100	42	0.012	0.004	0.152
120×108	43	0.091	0.0036
120	44	0.081	0.32	0.131
140	46	0.061	0.0024	0.12
150	46	0.061	0.0024	0.108
160	46	0.061	0.0024	0.098
180	47	0.051	0.002	0.09
200	47	0.051	0.002	0.076
