OVERVIEW

Material：low carbon steel wire, stainless steel wire, fiber wire, aluminum magnesium alloy wire, galvanized wire, PVC wire, aluminum wire, etc.

Weaving: divided into I type and II type

Character: light weight, good toughness, corrosion-resistance, good ventilation and easy cleaning



Usage: used in restraint, public building, civil building to keep away mosquito and fly.

Window series: stainless steel window screen, paint  window screen, galvanized window screen, al-mg window screen, PVC coated window screen, fiberglass window screen, and others.

Product name	Specifications			Notes
	Mesh	Wire Gauge	Dimension
Galvanized   window screen	10x10	BWG31 BWG32 BWG33 BWG34	3"x100" 4"x100" 1x25M 1.2x30M 1.5x25M	Electro   galvanized. after weaving
	14x14
	16x16
	18x18			White   and blue white
	18x14
	22x22
	24x24
Paint   steel window screening	Same   as above(Enameled)			Green   or dark green
Aluminum   paint steel window screening	Same   as above			Silver,   white
Aluminum   window screening	Same   as above			Al-mg   wire or aluminum wire, paint aluminum window screen (epoxy)
Fiberglass   window screening	12x12	BWG31 BWG32	3"x100"	Varies   colors
	14x14		4"x100"
	16x16		1x25M
	16x14		1.2x25M
Plastic   window screening	12x12	Same   as above		Mesh   12，14，16 is twill weaving。Mesh 18，22，24 is plain weaving。 White,   blue and green, etc.
	14x14
	16x16
	18x18
	18x14
	20x20
Stainless   steel window screening	14x14	SWG38 SWG37 SWG36 SWG35 SWG34	3"x100"   4"x100" 1x25M 1.2x25M	Material   304，316，316L
	16x16
	18x18
	18x14
	20x20
PVC   coated window screening	12x12	BWG31   BWG32	Same   as above	Apply   to oil, pipeline, package, various colors
	14x14
	16x16
	18x18
